零件名稱
Part name |
閥桿、閥蓋
Body 、Bonnet |
閥桿、閥瓣
Stem、Disc |
填料
Packing |
|
J24W-160P-DN3
|
鉻鎳不銹鋼
Cr. Ni Stainless steel |
鉻鎳不銹鋼
Cr. Ni Stainless steel |
聚四氟乙稀，柔性石墨
PTFE，Soft graphite |
|
J24W-320P-DN6
|
優質碳鋼
High grade carbon steel |
鉻，鎳不銹鋼
Cr. Ni Stainless steel |
聚四氟乙稀，柔性石墨
PTFE，Soft graphite |
|
型號
Type |
公稱壓力PN Mpa
|
試驗壓力PS(Mpa)_Test pressure
|
工作壓力(Mpa) Working pressure
|
工作溫度(OC) Working temps.
|
適用介質Applicable medium
|
||
|
殼體
Shell |
密封(液)Seal
|
密封(氣)Seal
|
|||||
|
J24W-160P-DN3
|
16.0
|
24.0
|
17.6
|
0.6
|
16.0
|
P≤540OC
|
液化石油氣水，酸，蒸汽，油品等 Petroleum gas Water，As，Steam，Oil，etc.
|
|
J24W-320P-DN6
|
32.0
|
48.0
|
35.2
|
0.6
|
32.0
|
C≤425 OC
|
|
|
型號
Type |
公稱直徑DN（mm）
|
尺寸 Dimension
|
重量(kg)Weight
|
|||||
|
L1
|
Do
|
H
|
H1
|
D
|
D1
|
|||
|
J24W-160P-DN3
|
3
|
80
|
65
|
159
|
168
|
14
|
3
|
1.0
|
|
J24W-320P-DN6
|
6
|
80
|
65
|
159
|
168
|
14
|
6
|
1.0
|
